Product Name: 400 Ton Double Crank Mechanical Press Manufacturer: MECFOND Model No: TIPO S2-400-2800 x 1600 Machine No: P0045 Technical Details:

Press Power : 400 Ton

Top Board Stroke : 600 mm

Regulation : 300 mm

Distance from the base to up Table : 1500 mm

Light between the uprights : 2850 mm

Lower Table Dimensions : 2800 X 1600 mm

Step Hole : 100 mm

Upper Table Dimensions : 2800 X 1600 mm

Lower Cushion Type : 2-8-38-9

Max Power : 73 T

Max Stroke : 230 mm

Lower Cushion Size : 2460 X 1140 mm

Max Dimensions Size : 4600 X 2400 X 7100 mm ( from floor plan)
